- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS
- Product Series
- SMT
- Product Type
- Line-interactive UPS
- Technical Information
- Receptacle Type
- IEC 60320 C19
- IEC Jumper
- IEC 60320 C13
- Receptacle Detail
- 1 x IEC 60320 C19
- 3 x IEC Jumper
- 8 x IEC 60320 C13
- Number of Battery & Surge Outlets
- 12
- Transfer Time
- 10 ms
- Application/Usage
- Server
- POS Terminal
- Router
- Switch
- Network Hub
- Power Description
- Load Capacity (VA)
- 2.20 kVA
- Load Capacity (Watt)
- 1.98 kW
- Input Voltage
- 230 V AC
- Input Voltage Range
- 160 V AC - 286 V AC
- Output Voltage
- 230 V AC
- 240 V AC
- Waveform Type
- Sine Wave
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Battery Information
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 5.50 Minute
- Typical Battery Recharge Time
- 3 Hour
- Hot Swappable
- Yes
- Physical Characteristics
- Height
- 86 mm
- Width
- 480 mm
- Depth
- 683 mm
- Rack Height
- 2U
- Form Factor
- Rack-mountable
- Weight (Approximate)
- 42.31 kg
- Miscellaneous
- Environmentally Friendly
- Yes
