- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Symmetra
- Product Series
- RM
- Product Type
- Double Conversion Online UPS
The first UPS with redundancy and scalability within a single chassis!
Engineered to deliver the highest level of business continuity possible, Symmetra RM 2kVA uses a modular, redundant architecture that can scale power and runtime as demand increases or when higher levels of availability are required. Symmetra's integrated manageability, and hot-swappable, user replaceable power, battery, and intelligence modules enable easy, fast maintenance and serviceability. Its 2-6kVA N+1 redundant rack-optimized form factor makes Symmetra ideal for protecting critical server racks and network rooms. Typical applications include Web and other key application servers, IP based and traditional PBX voice solutions, and enterprise type network switches.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Plug/Connector Type
- Hard Wire 3-wire
- Receptacle Type
- IEC 320-C13
- IEC 320-C19
- Receptacle Detail
- 8 x IEC 320-C13
- 2 x IEC 320-C19
- Number of Battery & Surge Outlets
- 10
- Dataline Protection
- RJ-45
- Overload Protection
- Yes
- Power Description
- Load Capacity (VA)
- 2 kVA
- Input Voltage
- 220 V AC
- Output Voltage
- 230 V AC
- Input Frequency
- 60 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Management
- Network Management
- SNMP Manageable
- Alarm
- On Battery
- Low Battery
- Configurable Delay
- Bypass Switch
- Internal
- Emergency Power OFF
- Yes
- Interfaces/Ports
- Modular Slots
- 1 x SmartSlot
- Battery Information
- Battery Characteristics
- Spill-proof/Maintenance-free
- Battery Chemistry
- Lead Acid
- Backup/Run Time (Full Load)
- 12.60 Minute
- Backup/Run Time (Half Load)
- 29.80 Minute
- Typical Battery Recharge Time
- 4 Hour
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Sound Emission (A-Weighted)
- 60 dB(A)
- Thermal Dissipation
- 590 BTU/h
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Rack-mountable
- Rack Height
- 8U
- Height
- 356 mm
- Width
- 483 mm
- Depth
- 730 mm
- Weight (Approximate)
- 74.55 kg
- Miscellaneous
- Package Contents
- Symmetra 2kVA Scalable to 6kVA Rack-mountable UPS
- CD with software
- Rack Mounting Brackets
- Rack Mounting support rails
- User Manual
- Additional Information
- Automatic restart of loads after UPS shutdown
- InfraStruXure Manager Compatible
- Plug-and-Play external batteries
- Configurable for 220, 230 or 240 nominal output voltage
- Certifications & Standards
- C-tick, CE, EN 50091-2, EN 60950, IRAM, VDE
