- General Information
- Manufacturer
- Lantronix, Inc
- Manufacturer Website Address
- http://www.lantronix.com
- Brand Name
- Lantronix
- Product Type
- Ethernet Switch
This switch is an unmanaged full Gigabit Ethernet hardened PoE++ switch that complies with IEEE 802.3bt, IEEE 802.3at and IEEE 802.3af. The switch has (4) 10/100/1000Base-T PoE++ ports, (1) 10/100/1000Base-T port with (1) 100/1000 dual speed SFP slot. It can deliver up to 90 Watts on each PoE++ port simultaneously and also supports Power over HDBaseT (PoH) mode (95 Watts) when enabled by DIP switch. The SISTP1040-551-LRT can be used to power PoE lighting, high powered IP cameras and digital signage. It has redundant input power connections to ensure safe reliable operation in temperatures between -40°C and +75°C.
- Warranty
- Limited Warranty
- 5 Year
- Technical Information
- Features
- Fanless
- Interfaces/Ports
- Total Number of Network Ports
- 5
- Modular
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 1 x Gigabit Ethernet Network
- 4 x Gigabit Ethernet PoE++
- 1 x Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Optical Fiber
- Twisted Pair
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 10/100/1000Base-T
- 100/1000Base-X
- I/O Expansions
- Total Number of Expansion Slots
- 1.0
- Expansion Slot Type
- SFP (mini-GBIC)
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3bt
- IEEE 802.3at
- IEEE 802.3af
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3z
- IEEE 802.3x
- IEEE 802.1p
- Management & Protocols
- Manageable
- No
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 360 W
- Input Voltage
- 48 V DC
- 57 V DC
- 120 V AC
- 230 V AC
- Power Source
- AC/DC
- Power Consumption
- 5 W
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- DIN Rail Mountable
- Wall Mountable
- Height
- 129.5 mm
- Width
- 61 mm
- Depth
- 104.1 mm
- Weight (Approximate)
- 952.5 g
