Allied Telesis CentreCom FS980M/28 Ethernet Switch

  • Part: 1177470
$235.00

Availability

In Stock

  • General Information
    • Manufacturer
    • Allied Telesis, Inc
    • Manufacturer Website Address
    • http://www.alliedtelesis.com
    • Brand Name
    • Allied Telesis
    • Product Line
    • CentreCOM
    • Product Series
    • FS980M
    • Product Type
    • Ethernet Switch

Fast Ethernet Managed Access Switches

Allied Telesis CentreCOM FS980M switches feature centralized network management via Allied Telesis Management Framework (AMFTM), and a redundant system with Virtual Chassis Stacking (VCStackTM). These high-performing switches deliver flexible uplink connectivity and lower management costs.

Overview
FS980M switches provide high-performance Fast Ethernet connectivity right where you need it-at the network edge. Flexible and robust, the FS980M series provide total security and management features for enterprises of all sizes. They also support video surveillance and Point of Sale (POS) applications.

Reduce network running costs by automating and simplifying many dayto-day tasks-an FS980M is the ideal AMF edge switch when an AMF Master switch is available in the network.

With both copper and Power over Ethernet (PoE) models, the FS980M Series has the ideal solution for your network. All models are available with 8, 16, 24 and 48 × 10/100TX Fast Ethernet ports. PoE models support the IEEE 802.3at (PoE+) standard, delivering up to 30 Watts of power per port for video surveillance and security applications.

  • Interfaces/Ports
    • Total Number of Network Ports
    • 28
    • Uplink Port
    • Yes
    • Modular
    • Yes
    • Stack Port
    • Yes
    • Network (RJ-45)
    • Yes
    • Port/Expansion Slot Details
    • 24 x Fast Ethernet Network
    • 4 x Gigabit Ethernet Expansion Slot
  • Media & Performance
    • Media Type Supported
    • Optical Fiber
    • Twisted Pair
    • Ethernet Technology
    • Fast Ethernet
    • Gigabit Ethernet
    • Network Technology
    • 10/100Base-TX
    • 1000Base-T
    • 1000Base-X
  • I/O Expansions
    • Total Number of Expansion Slots
    • 4.0
    • Expansion Slot Type
    • SFP (mini-GBIC)
    • Number of SFP Slots
    • 4
  • Network & Communication
    • Layer Supported
    • 3
    • Networking Standards
    • IEEE 802.1x
    • IEEE 802.2
    • IEEE 802.3
    • IEEE 802.3ab
    • IEEE 802.3x
    • IEEE 802.3z
    • IEEE 802.1ab
    • IEEE 802.1p
    • IEEE 802.1D
    • IEEE 802.1s
    • IEEE 802.1w
    • IEEE 802.3ad
    • IEEE 802.1Q
    • IEEE 802.1v
    • IEEE 802.3ac
  • Management & Protocols
    • Manageable
    • Yes
  • Power Description
    • Frequency
    • 50 Hz
    • 60 Hz
    • Power Source
    • Power Supply
    • Number of Power Supplies Installed
    • 1
    • Power Consumption
    • 19 W
  • Physical Characteristics
    • Form Factor
    • Wall Mountable
    • Height
    • 43.2 mm
    • Width
    • 440 mm
    • Depth
    • 257 mm
    • Weight (Approximate)
    • 3.20 kg
